Pedestrian Bridge Design

10× the required load capacity. One of the lightest bridges in the class.

  • Remote controlled robot detail
  • Remote controlled robot mechanism
  • Remote controlled robot fourth ticker image
  • Remote controlled robot assembly

Class:

ENGS 33: Solid Mechanics

OVERVIEW

Designed, analyzed, and constructed a scale model pedestrian bridge meeting AASHTO and IBC structural requirements. The final design carried 10.01 kN — ten times the minimum requirement — while deflecting just 1.05 mm at midspan and weighing only 527 g, placing it among the lightest in the class.

The key insight driving the result: widening critical top members is more structurally efficient than adding new ones. That single decision — replacing more material with better-placed material — is what enabled the high load-to-weight ratio.

MY ROLE.

  • Produced preliminary conceptual sketches and CAD drawings exploring truss configurations across strength, weight efficiency, and aesthetics

  • Conducted hand calculations and SolidWorks FEA under three load cases: distributed pedestrian load (0.156 kN/m), central point load (1 kN), and railing point load (0.1 kN)

  • Identified unsafe top members under load and proposed widening them rather than adding new members — the decision that drove the final design's efficiency

  • Iterated FEA simulations with teammates to reduce peak stress concentrations across the structure

  • Fabricated the final bridge from laser-cut birchwood (3 mm and 6 mm) assembled with wood glue and clamps

  • SolidWorks CAD • Finite Element Analysis (FEA) • Structural Analysis • Iterative Prototyping
